Product Details:
|
Applicable Industries: | Building Material Shops, Energy & Mining | Showroom Location: | None |
---|---|---|---|
Condition: | New | Type: | Magnetic Separator |
Production Capacity: | 1-220t/h | Voltage: | 220V/380V |
Dimension(L*W*H): | Different Model | Weight: | 3000-10000kg |
Warranty: | 1 Year | Product Name: | Magnetic Seperator |
Company Namw: | Weifang Guote Mining Equipment Co.,Ltd. | Application: | Mining |
Feeding Size: | 0-1mm | Capacity: | 1-220t/h |
Roller Length: | 750*1200-1500*4000mm | Model: | CTB/N/S |
Material: | Carbon Steel | Service: | OEM |
Installation: | Engineer Guide | Local Service Location: | None |
After-sales Service Provided: | Video Technical Support, Free Spare Parts, Online Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service | Port: | Qingdao Port |
CTB:Semi-countercurrent roller :0-0.5mm sand
CTS:Clockwise roller :0-0.6mm sand
CTN:Counterclockwise roller:0-6mm sand
1.Introduction
Permanent magnet drum magnetic separator is suitable for mines, coal preparation plant and other units. For weak magnetic field wet fine particles of strong magnetic minerals, or in addition to without strong magnetic mineral mixed magnetic minerals.The machine the same cylinder admirable three tub: half counter—current slot (CTB), counter—current slot (CTN) and the down-stream slot (CTS) applicable to different sorting granularity and different sorting process requirements. This product USES the computer optimization design, magnetic circuit is reasonable and strict selection of high coercive force, high residual magnetism of permanent magnet, ensure magnetic over a long time not to reduce, ensure long-term interests of the users, the overall structure is reliable and durable.
2.Working Principle
Pulp through the hopper into the magnetic field, the strong magnetic minerals adsorb on the cylinder surface, weak magnetic and non—magnetic minerals to wash out by water, and adsorption on a cylinder surface magnetic minerals with cylinder rotation, the area is out of the field, by washing in the water tank into concentrate, complete the sorting operation.
Weifang guote Mine Equipment Co., Ltd. is a research and development, engineering design, production and installation, commissioning services as one of the professional production of mining equipment, automation control equipment and the provision of non-metallic mineral production line test, design, consultation and the whole line delivery of the modern enterprise. The scope of services related to mining, metallurgy, electric power, coal, glass, paper, chemical building materials, refractory materials, tiles, food, cement and other industries, products are sold in more than thirty provinces, autonomous region.
The company products are: electromagnetic, permanent magnetic separator, dry wet magnetic separator, electromagnetic vibration feeder, quartz sand making machine, air classifier, dust collector, water separator, washing machine, flotation machine, metal detector, screw conveyor, timing quantitative feeding weigher, centralized control system and other products.
1. EPC service for single equipment and whole production line.
2.OEM service for your personal equipment or production line .
3.Testing before delivery and Pretesting in working site until get qualified products .
4.24hours for technical Operation Guide and 4hours offer technical proposal for problem shooting.
Q: Why we believe in Weifang GuoteMining Equipment Company?
A:
1. More than 10 years experience.
2. We are the leading professional supplier of mining equipments and service for quartz mining equipment industry.
3. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.
Q: Delivery time
A: The lead time is 10-30 days, Delivery time will vary depending on the type of the machine, shipping method selected and part availability.
Q: Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash
After sign the contract, pay the 30% deposit of total purchase price and pay the full payment before delivery.
Q: what will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.
Q: What should i do if I want to get a best quotation?
A: If you want a suitable type for you ,please let us know your material and capacity.
