≤3.9kw High Gradient High Intensity Dry Magnetic Separation Graphite Powder Separator

Large Image : ≤3.9kw High Gradient High Intensity Dry Magnetic Separation Graphite Powder Separator

Product Details:

Place of Origin:	Shandong, China
Brand Name:	guote

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$20,000.00/sets >=1 sets
Packaging Details:	Special boxes and containers (sea transport) for Nice Quality laboratory magnetic separator
Supply Ability:	500 Set/Sets per Month Nice Quality laboratory magnetic separator

Contact Now

≤3.9kw High Gradient High Intensity Dry Magnetic Separation Graphite Powder Separator

Description

Applicable Industries:	Energy & Mining	Showroom Location:	None
Condition:	New	Type:	Magnetic Separator, Magnetic Separator
Production Capacity:	15-140m3/h, 200-500kg/h Support Customization	Voltage:	380V
Dimension(LWH):	300400540mm	Weight:	200 KG
Warranty:	1 Year	Marketing Type:	Ordinary Product
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Motor, Engine
Key Selling Points:	Multifunctional, High-accuracy	Material:	Stainless Steel
Usage:	Mining Separatoion	Recovery Rate:	95-98%
Cooling Type:	Oil And Water Compound	Adapt Material:	<3mm Powdery And Granular
Magnetic Induction:	21000 GS Adjustable	Power:	≤3.9kw
Port:	QingDao

Product Description

GTDZ series electromagnetic sizing agent magnetic separator is the latest magnetic separation products developed by our company ,The background magnetic field reaches 1.5t ,High magnetic field gradient .
It can be equipped with a variety of special magnetic stainless steel media to meet the needs of different minerals in different regions

Specification

Unique electromagnetic coil design and efficient cooling method

Outstanding advantages:

Unique electromagnetic coil design and efficient cooling method

---The magnetic coil of the magnetic separator of electromagnetic paste is cooled with fully sealed cooling oil, and the external high-efficiency heat exchanger is used for heat exchange of oil and water to realize compound cooling of oil and water, with fast cooling speed, low temperature rise and stable magnetic field The separation medium produces high magnetic field gradient, and the removal of iron is better

---The medium is made of special magnetic-conducting stainless steel, which can generate extremely high gradient magnetic field under the excitation of background magnetic field. It has a strong adsorption effect on low content of weak magnetic impurities and a better effect on iron removal

Fully automatic operation, low operating and maintenance cost
---The working process of this equipment is controlled by automatic program, which can realize automatic operation without human being on duty and reduce operation and maintenance cost High pressure water positive and reverse washing, iron removal clean, no residue
--- When removing iron from the equipment, use high pressure water to clean the medium and remove iron cleanly. The cleaning time can be set according to different mineral stages to improve the treatment efficiency

Electromagnetic sea sand slurry magnetic separator is used for iron removal and purification of nonmagnetic ores such as quartz ,feldspar ,kaolin and other minerals . It can also be used for waste water treatment and clean of contaminated chemical materials in iron and steel power plants.
