Dry Processing Magnetic Drum Separator GCX Series with 350 KG Capacity

Large Image : Dry Processing Magnetic Drum Separator GCX Series with 350 KG Capacity

Product Details:

Place of Origin:	Shandong, China
Brand Name:	GUOTE

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$2,989.00/sets 1-1 sets
Packaging Details:	Characteristics of wooden box / container sea transport
Supply Ability:	500 Set/Sets per Month magnetic separator

Contact Now

Dry Processing Magnetic Drum Separator GCX Series with 350 KG Capacity

Description

Applicable Industries:	Energy & Mining	Showroom Location:	Turkey, Viet Nam, Philippines, Indonesia, Pakistan, India, Thailand, Sri Lanka, Uzbekistan, Tajikistan, Malaysia, Australia
Condition:	New	Type:	Magnetic Separator
Production Capacity:	1-5	Voltage:	440/380
Dimension(LWH):	12001002000	Weight:	350 KG
Warranty:	1 Year	Marketing Type:	Ordinary Product
Machinery Test Report:	Provided	Video Outgoing-inspection:	Provided
Warranty Of Core Components:	1 Year	Core Components:	Other
Key Selling Points:	Long Service Life	Outline Dimension:	200611001450mm
Roller Length:	1200mm	Magnetic Induction Intensity:	1000-13000Gs
Roller Speed:	17-82r/min	Productivity:	≤5T/h
Material Size:	≤10mm	Motor Power:	3kw
Material:	Q235

Drum magnetic separator GCX II series permanent magnet drum magnetic separator

Dry Processing Magnetic Drum Separator GCX Series with 350 KG Capacity 0

Product Description

Scope of application:

In addition to the selection of dry of a miscellaneous and hematite, limonite of powdery or granular material in removing iron contaminants, used for refractory materials, glass, ceramics, abrasives and other non-metallic ore purification, chemical, food and non magnetic metal ore.

Technical characteristics:
1, equipped with vibrating feeder feeding.
2, rare earth permanent magnetic material as magnetic source, through the depth of the magnetic depth, strong suction.
3, the new type of compensation magnetic pole type magnetic system, the magnetic field strength is higher, the gradient is bigger.
4, the swing of the magnetic system, increase the magnetic flow through the tube when the roll of the number of times, the election results better.
5, the whole machine maintenance free, safe and reliable use.
6, continuous automatic removal of debris.
7, can be made of two or more tube type.
8, there are four kinds of magnetic force to choose.

ITEM	Dimension	Drum	φD	Magnetic intensity	Roller number	Drum speed	productivity	Material particle	Motor power
	mm	mm	mm	Gs		R/min	Ton/hour	mm	kw
GXC-40-1	550460460	400	300	1000-10000	1	17-82	0.6	5	0.55
GXC-60-1	830710930	600	400	1000-10000	1	17-82	1.5	5	0.75
GXC-60-11	10709251240	600	320	1000-10000	2	17-82	2	5	1.5
GXC-60-111	115010701700	600	406	1000-10000	3	17-82	2.5	6	1.5
GXC-80-1	11808201040	800	406	1000-10000	1	17-82	2	8	0.75
GXC-80-11	142012201570	800	406	1000-10000	2	17-82	2.5	8	1.5
GXC-80-111	177012601570	800	406	1000-10000	3	17-82	3	8	2.2
GXC-100-1	130010201240	1000	508	1000-10000	1	17-82	2.5	10	3
GXC-100-11	162014602309	1000	508	1000-10000	2	17-82	4	10	4
GXC-100-111	197014602309	1000	508	1000-10000	3	17-82	5.5	10	5.5

Dry Processing Magnetic Drum Separator GCX Series with 350 KG Capacity 1
