Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand

Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand

Large Image :  Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $50,000.00/sets >=1 sets
Packaging Details: standard export container,20GP,40GP ,40HQ,FR container,in bulk, <br> the spare parts in wooden case or according to the customer's requirements.
Supply Ability: 100 Set/Sets per Month
Contact Now

Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand

Description
Warranty: 1.5 Years Applicable Industries: Energy & Mining
Weight (KG): 1000 Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: PLC Condition: New
Product Name: Three Cylinder Dryer Heating Method: Gas Heating
Usage: Drying Sand Below 20-40mm Material: SS304
Capacity: 10-50tph Input Moisture: 10-15%
Output Moisture: 1% Installation: Under Engineer's Guidance
Voltage: 380V Keywords: Dryer

Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 0
Products Description
Three-cylinder dryer equipment can dry dry mortar, yellow sand, cement slag, clay, gangue, mixture, fly ash, gypsum, iron powder and other raw materials, widely used in building materials, chemicals, castings, etc. industry.The three-cylinder dryer improves the internal structure of the original single-barrel dryer, increases the pre-drying of the wet material before entering the machine and prolongs the drying time of the wet material in the machine, plus sealing, heat preservation and reasonable supporting measures to make the dryer dry. Machine production capacity is 48-80% higher than the original single drum dryer.Evaporation intensity per unit volume up to 120-180kg/m3, It has advanced technology, reasonable operating parameters, simple and feasible operation.
Details Images
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 1

1. Three cylinder dryer equipment investment is 1/6 of imported products, made of alloy steel plate, 3-4 times more wear than ordinary steel plate.
2. Material can be customized according to demand 304, 316 stainless steel, ultra-pure production, eliminate impurity
contamination.
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 2

3. The thermal efficiency of the three-cylinder dryer is as high as 80%, and the thermal efficiency is increased by 48%.
4. The three-cylinder dryer reduces the floor space by about 50% compared to the single-cylinder dryer and reduces the civil engineering investment by about 50%.
5. The fuel can be adapted to coal, oil and gas, and can bake blocks, granules and powder materials below 20-40mm.
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 3

6. According to user requirements can easily regulate the desired final moisture index.
7. The machine adopts a material and hot air flow drying process,with a wide range of applications
Product Paramenters
Model
Diameter of outer cylinder
Length of outer cylinder
Cylinder volume
Weight
Rotating Speed
(rpm)
Productivity
(t/h)
GZS163
1.6
3
5.3
6
8-10
4.5-7.5
GZS214
2.1
4
12.6
7.4
10.6-17.8
GZS265
2.6
5
24..5
15.3
20.6-34.7
GZS306
3
6
36.9
32
31.1-52.2
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 4
Company Profile
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 5
Basic Company Introduction
Weifang guote mining equipment Co.,Ltd. is located in Qingzhou Economic Development Zone, Weifang City, Shandong Province. It covers an area of 40000 square meters. It is a high-tech enterprise in Shandong Province. The company has passed ISO9001 quality system certification, environmental system certification, safety management system certification, EU CE certification and more than ten useful national invention patents.
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 6
About GUOTE
Guote Mining equipment has long been committed to the production of quartz sand, silicon powder, feldspar and oil field fracturing
sand special equipment, and provide non-metallic ore production line experiment, design, consulting and the whole line equipment supply;such as：quartz sand making processing line equipment;glass sand making processing line equipment ;quartz powder making machine;sand washing system;drum dryer machine;dewatering screen equipment;vibration screen;scrubber attrition machine;magnetic separator machine...etc...
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 7
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 8
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 9
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 10
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 11
Certifications
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 12
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 13
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 14
Customer Photos
Under Engineer's Guidance SS304 Industrial Sand Rotary Dryer for Drying Silica Sand 15

About customers：

Our products are very popular at home and abroad, exported to Japan, South Korea,Thailand, Pakistan, Bangladesh, South Africa, India, Indonesia, Brazil, Vietnam, Malaysia and more than a dozen other countries and regions.
