Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier

Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier

Large Image :  Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier

Product Details:
Place of Origin: Shandong, China
Brand Name: guote
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $6,500.00/sets >=1 sets
Packaging Details: Special boxes and containers (sea transport) for Nice Quality laboratory magnetic separator
Supply Ability: 500 Set/Sets per Month Nice Quality laboratory magnetic separator
Contact Now

Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier

Description
Applicable Industries: Energy & Mining, Building Material Shops, Energy & Mining Showroom Location: None
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: Motor Condition: New
Voltage: 220v/380v Power: 55-120kw
Dimension(L*W*H): Different Model Weight: 2000 Kg
Warranty: 1 Year Key Selling Points: High Efficiency
Capacity(t/h): 1-20t/h Feeding Particle Size: ≤300mm
Product Particle Size: 4-120 Mesh

Product Description
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 0
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 1
Dry quartz powder Ball Mill quartz Powder Plant
mainly used for mineral processing, chemical, medicine, building materials, quartz powder for plate etc.
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 2
Ball Mill
Ball Mill can used to produce high purity quartz powder with 200-1250mesh, the product has many advantages such as high purity,good whiteness and stable granularity .
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 3
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 4
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 5
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 6
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 7
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 8
Outstanding Advantages:
The materials which less than 10mush, from feeding apparatus through the feeding hollow shaft screw enter into mill warehouse homogeneous, the warehouse is equipped with a ceramic liner plate with steel and jade balls of different specifications, the centrifugal force generated by the rotation of the cylinder brings the dielectric ball to a certain height and then falls down,impact and grinding on materials. The powder that meets the requirement is discharged through the discharge grate, finish the milling operation. After grinding, the material enters the classifier from the inlet, by adjusting the speed of the classifying wheel (frequency control, stepless speed regulation) and reasonable secondary wind, a reasonable and stable gas-solid two-phase flow is formed in the grading zone, the interaction between centrifugal force and the negative pressure of the fan is generated by the rotation of the classifying wheel to realize effective grading of materials. The coarse particles are returned to the ball mill by the coarse material return device to continue grinding, and the finished products are packaged by the automatic packaging machine. The whole system is equipped with a dust precipitator using more advanced electromagnetic pulse automatic ash removal,the dust is filtered by the filter bag after the dust-carrying gas enters the dust collector,dust attached to the outer surface of the filter bag is scattered at the bottom under the action of pulse blowback gas. The filtered clean gas is discharged into the atmosphere through the fan.
Specification
Model
Ball mill machine
Classification model NO.
Total Power
Capacity
Fineness
Classification
accuracy
Filtration area
Dust concentration
Working system
GMF-100
Φ1500*5700
GF100
≤145
1.2-8
5-50
D97
≥70
≤40
Continuous
GMF-200
Φ1830*7000
GF200
≤225
3.5-4
5-50
D97
≥100
≤40
GMF-400
Φ2200*7500
GF400
≤345
5-6
5-50
D97
≥120
≤40
Packing & Delivery
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 9
Motor Core Components Energy-Saving Gypsum Powder Ceramic Ball Mill With Air Classifier 10
1 Packaging: Specially made wooden boxes and containers
2 Shipping: 5-45 days after receiving initial payment
FAQ
Q: Why we believe in Weifang GuoteMining Equipment Company?
A: 1. More than 10 years experience.

Q. We are the leading professional supplier of mining equipments and service for quartz mining equipment industry.
A. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.

Q: Delivery time
A: The lead time is 10-30 days, delivery time will vary depending on the type of the machine, shipping method selected and part
availability.

Q: Payment terms
A: Accepted Payment Type: T/T, L/C, Western Union, Cash.
After sign the contract, pay the 30% deposit of total purchase price and pay the full payment before delivery.

Q: What will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the
machine is in trouble. For those wear parts, we guarantee the high quality parts for long-term supply.

Q: What should I do if I want to get a best quotation?
A: If you want a suitable type for you, please let us know your material and capacity.
