Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime

Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime

Large Image :  Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $68,000.00/sets >=1 sets
Contact Now

Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime

Description
Warranty: 1.5 Years Applicable Industries: Manufacturing Plant, Farms, Construction Works , Energy & Mining
Weight (KG): 2000 Showroom Location: Viet Nam, Indonesia, India, Ukraine, Malaysia
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Ordinary Product Warranty Of Core Components: 1 Year
Core Components: PLC Condition: New
Initial Moisture Of Quartz Sand: 15-18% Final Moisture Of Quartz Sand: 0.5-1%
Adapt To Material Size: Block, Granular And Powdery Materials Below 20-40mm After-sales Service Provided3: Online Support
After-sales Service Provided1: Video Technical Support After-sales Service Provided2: Field Installation, Commissioning And Training
After Warranty Service1: Video Technical Support After Warranty Service2: Online Support

Product Overview

GHS Three cylinder dryer

feeding size is block, granular and powdery materials below 20-40mm
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 0

1. Three cylinder dryer equipment investment is 1/6 of imported products, made of alloy steel plate, 3-4 times more wear than
ordinary steel plate.
2. Material can be customized according to demand 304, 316 stainless steel, ultra-pure production, eliminate impurity
contamination.
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 1

Outstanding Advantages

3. The thermal efficiency of the three-cylinder dryer is as high as 80%, and the thermal efficiency is increased by 48%.
4. The three-cylinder dryer reduces the floor space by about 50% compared to the single-cylinder dryer and reduces the civil
engineering investment by about 50%.
5. The fuel can be adapted to coal, oil and gas, and can bake blocks, granules and powder materials below 20-40mm.
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 2

6. According to user requirements can easily regulate the desired final moisture index.
7. The machine adopts a material and hot air flow drying process,with a wide range of applications
PRODUCT SPECIFICATIONS
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 3
Model
Diameter of outer cylinder
Length of outer cylinder
Cylinder volume
Weight
Rotating Speed
(rpm)
Productivity
(t/h)
GZS163
1.6
3
5.3
6
8-10
4.5-7.5
GZS214
2.1
4
12.6
7.4
10.6-17.8
GZS265
2.6
5
24..5
15.3
20.6-34.7
GZS306
3
6
36.9
32
31.1-52.2
Introduction
Three-cylinder dryer equipment can dry dry mortar, yellow sand, cement slag, clay, gangue, mixture, fly ash, gypsum, iron powder and other raw materials, widely used in building materials, chemicals, castings, etc. industry.The three-cylinder dryer improves the internal structure of the original single-barrel dryer, increases the pre-drying of the wet material before entering the machine and prolongs the drying time of the wet material in the machine, plus sealing, heat preservation and reasonable supporting measures to make the dryer dry. Machine production capacity is 48-80% higher than the original single drum dryer.
Evaporation intensity per unit volume up to 120-180kg/m3, It has advanced technology, reasonable operating parameters, simple and feasible operation.
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 4
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 5
Company Profile
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 6
Basic Company Introduction
Weifang guote mining equipment Co.,Ltd. is located in Qingzhou Economic Development Zone, Weifang City, Shandong Province. It covers an area of 40000 square meters. It is a high-tech enterprise in Shandong Province. The company has passed ISO9001 quality system certification, environmental system certification, safety management system certification, EU CE certification and more than ten useful national invention patents.
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 7
About GUOTE
Guote Mining equipment has long been committed to the production of quartz sand, silicon powder, feldspar and oil field fracturing sand special equipment, and provide non-metallic ore production line experiment, design, consulting and the whole line equipment supply;such as：quartz sand making processing line equipment;glass sand making processing line equipment ;quartz powder making machine;sand washing system;drum dryer machine;dewatering screen equipment;vibration screen;scrubber attrition machine;magnetic separator machine...etc...
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 8
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 9
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 10
our laboratory
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 11
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 12
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 13
Certifications
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 14
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 15
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 16
Customer Photos
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 17

About customers：

Our products are very popular at home and abroad, exported to Japan, South Korea,Thailand, Pakistan, Bangladesh, South Africa, India, Indonesia, Brazil, Vietnam, Malaysia and more than a dozen other countries and regions.
Services，packing，FAQ
1.EPC service for single equipment and whole production line. 2.OEM service for your personal equipment or production line  3.Testing before delivery  and Pretesting in working site until get qualified products  4.24hours for technical Operation Guide and  4hours offer technical proposal for problem shooting.
Industrial Three Drum Tumble Dryer for Automatic Drying of Large-scale Sand Slime 18
Q: Why we believe in Weifang GuoteMining Equipment  Company? A: 1. More than 10 years experience. Q. We are the leading professional supplier of mining equipments and service for quartz mining equipment industry. A. All products achieved ISO9001:2000 quality management certificate and EU CE certificate.
Q: Delivery time A: The lead time is 10-30 days, delivery time will vary depending on the type of the machine, shipping method selected and part availability.
Q: Payment terms A: Accepted Payment Type: T/T, L/C, Western Union, Cash.
After sign the contract, pay the 30% deposit of total purchase price and pay the full payment before delivery. Q: What will you do if the machine is broken down?
A: The Products warranty is one year. We will provide the technical advice and find the solution immediately for you when the machine is in trouble. For those wear parts, we guarantee the high quality
