Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation

Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation

Large Image :  Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3,000.00/sets >=1 sets
Packaging Details: Specially made wooden boxes and containers (sea transport),by 20 feet container/ 40 feet container ,and for large machinery, we use deck transportation or according to the customer's requirements
Supply Ability: 10 Set/Sets per Month
Contact Now

Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation

Description
Applicable Industries: Building Material Shops, Machinery Repair Shops, Energy & Mining Showroom Location: None
Condition: New Type: Magnetic Separator
Production Capacity: 0.1-35kg Voltage: 220V/380V
Dimension(L*W*H): Diffrent Model Weight: 750 KG
Warranty: 1 Year Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1.5 Years Core Components: PLC
Key Selling Points: Competitive Price Product Name: Mining Machine Mineral Separator Magnetic Separator
Company Name: Weifang Guote Mining Equipment Co.,Ltd. Model: Electromagnetic Separator
Belt Width: 500-2000mm Magentic Strength: 60-72MT
Belt Speed: 4.5m/s Magnet Type: N52
After Sale Service: Maintenance Spare Parts Supply: Anytime
Feature: High Magnetic Field Port: Qingdao Port

Product Description
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 0
Introduction
RCDB series dry type electromagnetic separator ( also named PDC Disc series or RCDY series) is one iron-ore collection device used for removing iron-ore from non miscellaneous material in powder or block shape. The internal part is electrical resin casting with self-cooling sealed structure.
Magnetic Penetration depth is higher, strong magnetic strength and anti-water/dust/ corrosion.It could be used in harsh working environment and could work with CF/CFL series suspension electromagnetic separators together.
The main performance factor is above JB/T7689-2004 standard required data and could remove 0.1 KG-5KG ferromagnetic ore from non-magnetic materials.
Specification
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 1
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 2
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 3

Features:
1)High magnetic field intensity, usually used in occasions with plenty of iron.
2)The wholly sealed structure makes the separator water-proof, dust- proof and corrosion resisting.
3)Made of rare earth NdFeB
4)High gauss
5)Energy saving
6)Easy to install and convenient to use.
7)High efficiency and stable performance.
8)Good operational reliability and flexibility
Model
Belt  width (mm)
Magnetic strength (MT)
Material thickness (mm)
Driving power (kw)
Belt speed (m/s)
RCDB-6
600
60
120
1.6
4.5
RCDB-8
800
70
200
3.6

RCDB-10
1000
70
250
5

RCDB-12
1200
70
300
6.8

RCDB-14
1400
70
350
9

RCDB-16
1600
70
400
13

RCDB-18
1800
72
450
18

RCDB-20
2000
72
500
23

Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 4
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 5
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 6
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 7
Automatic Cleaning Cross Belt Electromagnetic Separator for Iron Separation 8
