RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution

RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution
RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution

Large Image :  RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2,998.00/sets
Packaging Details: standard export container,20GP,40GP ,40HQ,FR container,in bulk, the spare parts in wooden case or according to the customer's requirements
Contact Now

RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution

Description
Applicable Industries: Energy & Mining Showroom Location: Viet Nam, Indonesia, Thailand, Sri Lanka
Condition: New Type: Magnetic Separator
Production Capacity: 98% Voltage: 380V
Dimension(L*W*H): Size Weight: 300 KG
Warranty: 1 Year Marketing Type: Other
Machinery Test Report: Not Available Video Outgoing-inspection: Not Available
Warranty Of Core Components: 1 Year Core Components: Motor
Key Selling Points: Long Service Life Product Name: Belt Magnetic Iron Separator
Keywords: Magnetic Separator Quality: Excellent
Color: Customers' Requirements Usage: Iron Separation
Advantage: High Separation Efficiency Installation: Technical Guidance
Feature: Simple Operation After-sales Service Provided: Video Technical Support

conveyor magnetic separator RCYD Self-cleaning Permanent suspended magnetic separator for belt conveyor sale
Alibaba china high intensity Series Guote RCYD Self-cleaning Permanent Magnetic Separators for belt conveyor sale



Features:



High magnetic field intensity, usually used in occasions with plenty of iron.



The wholly sealed structure makes the separator water-proof, dust-proof and corrosion resisting.



Made of rare earth NdFeB



High gauss



Energy saving



Easy to install and convenient to use.



High efficiency and stable performance.



Good operational reliability and flexibility



Mode

Usable

belt width

Standard

erection height

 Mass

Overall dimension (mm)

Unload

trigger spec.

Driving

motor power
(mm) (mm) (kg) A B C D E   (kw)
RCYD-6 650 200 880 2100 950 420 888 900 2.7 2.2
RCYD-8 800 250 1790 2050 1105 650 1038 1280 2.7 2.2
RCYD-10 1000 300 3060 2240 1310 785 1238 1370 3.3 2.2
RCYD-12 1200 350 4680 2440 1585 875 1512 1350 3.3 4
RCYD-14 1400 400 6600 2700 1765 970 1690 1550 4.1 4
RCYD-16 1600 450 8060 2900 1965 1050 1890 1750 4.2 4
RCYD-18 1800 500 10250 3150 2230 1150 2150 1960 6.8 5.5
RCYD-20 2000 500 12850 3380 2460 1280 2380 2170 16 5.5

RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution 0

  RCYD-6 Magnetic Separator Equipment for Energy Mining Low Energy Consumption Solution 1



Brief Introduction:

Self-discharge permanent-magnet separator series RCYD is energy

economizing type separator equipment using the latest third generation rare-earth permanent-magnet material NdFeB

to form magnetic system which produces strong magnet field attraction.

This product series links up with transferring equipments to form  a  complete set to remove the iron magnetic materials

 under weight of 0.1-25kg mixed among the non-magnetic materials.
