Large Capacity Hydraulic Classifier for Particle Sand Classification in Energy Mining

Product name: hydraulic classifier
The feeding size: < 5 mm
Production capacity: 0—50 t/h

Usage:Wet type sand screening machine

Application field:Mainly used in various industries with strict classification and selection of silica sand

Equipment introduction:Mainly used for fine mineral particle degree of classification

Advantages:

1, the material in the cylinder body by the rising water effect, achieve the purpose of sizing, the proportion of separation,high efficiency, low energy consumption.

2, equipped with automatic control system, the operation parameter adjustment is simple and convenient, easy to control.

3, a water tank at the bottom of the barrel is equipped with special devices and to rise above the water hole automaticallyshut down, the cylinder body of the material will not block the hole and into the tank.

 Extremely efficient washing of soluble or colloidal species from granular particles by virtue of counter-current plug flow washing.
High sharpness, little misplaced material via direct bed measurement
Multiple discharge valves on large units, to continue an even bed draw down without valve blockages or channeling
Multiple water injection nozzles result in uniform flow even at minimal flow rates
No moving parts are exposed to process slurry, meaning little maintenance is required and a long operating life is achievable
Low headroom design results in low capital installation and maintenance costs and easier inspection
Zero bypass, no fines in underflow
The flat bottom classifier is a well proven performer for the hydraulic classification of particles by size or density. The flat bottom classifier reliably extracts light or small particles from slurry at high efficiency, while displacing a minimum of heavy or coarse particles to the overflow.
