Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range

All Products

Magnetic Separator machine

(908)

Quartz Silica Sand Processing Line

(432)

Quartz Powder Processing Line

(291)

Mining Vibrating Screen

(210)

Mining Process Equipment

(92)

Quartz Purifying Equipment

(332)

Iron Remover Separator

(191)

Square Swing Screen

(50)

Automatic Metal Detector

(9)

Industrial Dryer Machine

(61)

Top Sale Product

(87)
Certification
China Weifang Guote Mining Equipment Co., Ltd. certification
China Weifang Guote Mining Equipment Co., Ltd. certification
I'm Online Chat Now

Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range

Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range

Large Image :  Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3,000.00/sets >=1 sets
Contact Now

Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range

Description
Applicable Industries: Energy & Mining Showroom Location: None
Condition: New Type: Magnetic Separator
Production Capacity: 98% Voltage: 220V/380V
Dimension(L*W*H): 1900*735*935 Weight: 750 KG
Warranty: 1 Year Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor
Key Selling Points: Self-discharging Application: Iron Removal
Rated Hang Height: 150mm-550mm Belt Width: 500-2000mm
Type:: Permanent Magnet Or Electromagnetic Keywords: Iron Separator
Color: Customers' Requirements Machine Type: Beneficiation Equipment
Installation: Engineer Guide Advantage: Self Discharging
Quality: China Standard

Product Description
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 0
Introduction
Guote RCYD Self-cleaning Permanent Magnetic Separators for belt conveyor is made up with permanent magnetic chip , iron-discharging belt, reducer, frame and roller etc. and can match with all kinds of conveyors.
It is used to eliminate the ferromagnetic material weighing from 0.1kg to 35kg .we adopt the computerized simulating and make it still work in the harsh environment for a long period.
Specification
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 1

Features:
1)High magnetic field intensity, usually used in occasions with plenty of iron.
2)The wholly sealed structure makes the separator water-proof, dust- proof and corrosion resisting.
3)Made of rare earth NdFeB
4)High gauss
5)Energy saving
6)Easy to install and convenient to use.
7)High efficiency and stable performance.
8)Good operational reliability and flexibility
Model
Belt  width (mm)
Magnetic strength (MT)
Material thickness (mm)
Driving power (kw)
Belt speed (m/s)
RCYD-6
600
60
120
1.5
4.5
RCYD-8
800
70
200
2.2
RCYD-10
1000
70
250
3
RCYD-12
1200
70
300
4
RCYD-14
1400
70
350
4
RCYD-16
1600
70
400
5.5
RCYD-18
1800
72
450
5.5
RCYD-20
2000
72
500
7.5
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 2
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 3
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 4
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 5
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 6
Packing and shipping
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 7
Recommend Products
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 8

RCYB Iron Separator

Permanent Magnetic Type
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 9

RCYD Iron Separator

Permanent Magnetic Type
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 10

RCYF Pipeline Iron Separator

Permanent Magnetic Type
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 11

RCDB Iron Separator

Electromagnetic Type
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 12

RCDD Iron Separator

Electromagnetic Type
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 13

RCYZ Pipeline Iron Separator

Permanent Magnetic Type
Company Profile
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 14
Basic Company Introduction
Weifang guote mining equipment Co.,Ltd. is located in Qingzhou Economic Development Zone, Weifang City, Shandong Province. It covers an area of 40000 square meters. It is a high-tech enterprise in Shandong Province. The company has passed ISO9001 quality system certification, environmental system certification, safety management system certification, EU CE certification and more than ten useful national invention patents.
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 15
About GUOTE
Guote Mining equipment has long been committed to the production of quartz sand, silicon powder, feldspar and oil field fracturing
sand special equipment, and provide non-metallic ore production line experiment, design, consulting and the whole line equipment supply;such as：quartz sand making processing line equipment;glass sand making processing line equipment ;quartz powder making machine;sand washing system;drum dryer machine;dewatering screen equipment;vibration screen;scrubber attrition machine;magnetic separator machine...etc...
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 16
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 17
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 18
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 19
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 20
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 21
Certifications
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 22
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 23
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 24
Customer Photos
Self Cleaning Belt Magnetic Separator with 98% Efficiency and 220V/380V Voltage Range 25

About customers：

Our products are very popular at home and abroad, exported to Japan, South Korea,Thailand, Pakistan, Bangladesh, South Africa, India, Indonesia, Brazil, Vietnam, Malaysia and more than a dozen other countries and regions.
