Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935

Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935

Large Image :  Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935

Product Details:
Place of Origin: Shandong, China
Brand Name: GUOTE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $3,000.00/sets >=1 sets
Contact Now

Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935

Description
Applicable Industries: Energy & Mining Showroom Location: None
Condition: New Type: Magnetic Separator
Production Capacity: 98% Voltage: 220V/380V
Dimension(L*W*H): 1900*735*935 Weight: 750 KG
Warranty: 1 Year Marketing Type: Ordinary Product
Machinery Test Report: Provided Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year Core Components: Motor
Key Selling Points: Self-discharging Application: Iron Removal
Rated Hang Height: 150mm-550mm Belt Width: 500-2000mm
Type:: Permanent Magnet Or Electromagnetic Keywords: Iron Separator
Color: Customers' Requirements Machine Type: Beneficiation Equipment
Installation: Engineer Guide Advantage: Self Discharging
Quality: China Standard

Product Description
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 0
Introduction
Guote RCYD Self-cleaning Permanent Magnetic Separators for belt conveyor is made up with permanent magnetic chip , iron-discharging belt, reducer, frame and roller etc. and can match with all kinds of conveyors.
It is used to eliminate the ferromagnetic material weighing from 0.1kg to 35kg .we adopt the computerized simulating and make it still work in the harsh environment for a long period.
Specification
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 1

Features:
1)High magnetic field intensity, usually used in occasions with plenty of iron.
2)The wholly sealed structure makes the separator water-proof, dust- proof and corrosion resisting.
3)Made of rare earth NdFeB
4)High gauss
5)Energy saving
6)Easy to install and convenient to use.
7)High efficiency and stable performance.
8)Good operational reliability and flexibility
Model
Belt  width (mm)
Magnetic strength (MT)
Material thickness (mm)
Driving power (kw)
Belt speed (m/s)
RCYD-6
600
60
120
1.5
4.5
RCYD-8
800
70
200
2.2
RCYD-10
1000
70
250
3
RCYD-12
1200
70
300
4
RCYD-14
1400
70
350
4
RCYD-16
1600
70
400
5.5
RCYD-18
1800
72
450
5.5
RCYD-20
2000
72
500
7.5
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 2
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 3
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 4
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 5
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 6
Packing and shipping
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 7
Recommend Products
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 8

RCYB Iron Separator

Permanent Magnetic Type
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 9

RCYD Iron Separator

Permanent Magnetic Type
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 10

RCYF Pipeline Iron Separator

Permanent Magnetic Type
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 11

RCDB Iron Separator

Electromagnetic Type
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 12

RCDD Iron Separator

Electromagnetic Type
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 13

RCYZ Pipeline Iron Separator

Permanent Magnetic Type
Company Profile
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 14
Basic Company Introduction
Weifang guote mining equipment Co.,Ltd. is located in Qingzhou Economic Development Zone, Weifang City, Shandong Province. It covers an area of 40000 square meters. It is a high-tech enterprise in Shandong Province. The company has passed ISO9001 quality system certification, environmental system certification, safety management system certification, EU CE certification and more than ten useful national invention patents.
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 15
About GUOTE
Guote Mining equipment has long been committed to the production of quartz sand, silicon powder, feldspar and oil field fracturing
sand special equipment, and provide non-metallic ore production line experiment, design, consulting and the whole line equipment supply;such as：quartz sand making processing line equipment;glass sand making processing line equipment ;quartz powder making machine;sand washing system;drum dryer machine;dewatering screen equipment;vibration screen;scrubber attrition machine;magnetic separator machine...etc...
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 16
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 17
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 18
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 19
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 20
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 21
Certifications
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 22
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 23
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 24
Customer Photos
Suspended Self Cleaning Iron Removing Sand Separator Dimension L*W*H 1900*735*935 25

About customers：

Our products are very popular at home and abroad, exported to Japan, South Korea,Thailand, Pakistan, Bangladesh, South Africa, India, Indonesia, Brazil, Vietnam, Malaysia and more than a dozen other countries and regions.
